Henkilökohtainen Body kamera Hikvision DS-MH2111

775,00

1 varastossa

Kuvaus

DS-MH2111

User Manual of DS-MH2111 Series Body Camera

Spec of DS-MH2111

Body worn camera
●     High Definition

Embedded with an image sensor of 16 megapixel and ISP suveillancelevel.

●     Image

Provides a lens whose horizontal FOV (Field of View) is 127°.

Supports distortion correction.

●     IR (Infrared Radiation) Light

Supports IR auto day and night switch

●     Video

Supports recording at up to 1080p/60fps.

Supports network transmission at high deifinition.

●     Tape

Supports recording while taping.

●     Network

Transmits real-time videos and audios to management platformvia built-in 4G module and Wi-Fi module.

●     Positioning

Built-in GPS and BeiDou positioning module.

●     Battery

A large capacity batterywith 4400 mAh capacity which can record videos of 1080p for 8 hours.

●     Video Output

Provides microHDMI interface totransmit image to external screen.

Sensor
Type: CMOS, 16MP
Lens angel: Horizontal FOV: 127°
Display
Displayer: 2.0″ TFT LCD
Video Parameter
IR light: Automatically turn on/off IR light.
Laser positioning: Supported
Recording: 1080p/60fps, 720p/120fps, 704*480
LED: Supported
Encoding format: H.264
Dual stream: Main stream: 1080p/60fps;
Sub-stream:720p/30fps
Picture resolution: Up to 16MP
Pre-record/post-record: Up to 60 s
Picture format: .jpg
Storage
Storage capacity: A built-in EMMC storage chip of 32GB capacity
Positioning
Satellite positioning: Built-in GPS module and built-in BeiDou module are provided.
Network
4G: Supported
Wi-Fi: 802.11b/g/n
performance
Working temperature: -20 to +55 °C (-4 to 131 °F)
Working humidity: ≤ 90%
Ingress protection: IP65
Structure
Weight: 220g (0.49 lb)
Dimension: 105 × 61 × 25 mm (41.3 × 24.0 × 9.8 ″)
Others
Data Interface: Mini USB 2.0
Battery: A battery with 4000 mAh capacity which can record videos of 1080p for 8 hours.
The battery can’t be uninstalled.
microHDMI interface: Supported
